3 Core Flexible Aluminium Pvc Flat Cables
TECHNICAL DATA | ||||
Size (mm2) | No. of Strands/ Dia in mm (Nom.) | Width (mm) | Height (mm) | Amps |
3C X 2.5 | 13/0.5 | 13.20 | 6.00 | 14 |
3C X 4 | 21/0.5 | 15.40 | 7.00 | 18 |
3C X 6 | 31/0.5 | 18.40 | 8.00 | 26 |
3C X 8 | 42/0.5 | 20.7 | 8.90 | 31 |
3C X 10 | 51/0.5 | 22.20 | 9.60 | 36 |
3C X 12 | 64/0.5 | 24.00 | 10.20 | 42 |
3C X 16 | 84/0.5 | 27.40 | 11.60 | 49 |
3C X 25 | 126/0.5 | 34.10 | 14.30 | 65 |
3C X 35 | 175/0.5 | 37.60 | 15.80 | 78 |
3C x 50 | 266/0.5 | 44.00 | 18.20 | 100 |
3C X 70 | 357/0.5 | 51.20 | 21.00 | 120 |
NOTE:
- THE NUMBER OF WIRES AND DIAMETER MENTIONED IN THE TABLE ARE APPROXIMATE AND NOMINAL, HOWEVER THEY SHALL MEET THE REQUIREMENTS OF CONDUCTOR RESISTANCE AS PER STANDARDS. IS 8130
- TOLERANCE: UP TO 4.0 SQ MM +/-0.5 MM. 6.0 SQ MM & 10 SQ MM +/-1.0 MM AND ABOVE 10 SQ MM +/-1.2 MM 3. THE ABOVE DATA IS INDICATIVE AND MAY BE REVISED WITHOUT PRIOR INFORMATION. NEONEX CABLES WILL NOT BE LIABLE FOR ANY DAMAGES ARISING OUT OF INCORRECT APPLICATION.
- THE ABOVE DATA IS INDICATIVE AND MAY BE REVISED WITHOUT PRIOR INFORMATION. NEONEX CABLES WILL NOT BE LIABLE FOR ANY DAMAGES ARISING OUT OF INCORRECT APPLICATION.
×
